Delta DF-1025

Features

  • PC Controller
  • Sanyo servo motors & Drivers
  • Rotating Wire & Quill
  • Servo Slides (8)
  • Full Set of Tooling (10 wire sizes)
  • 200 kgs. /440 lbs.  Decoiler
  • Options:
  • Spinners
  • Laser probes
  • Servo cutter
  • X-Y Slide
  • Super Spinner (2 axes)
Request a Quote

Specifications

Model DF-1025
Axes Std.: 10, Max: 16
Wire Capacity Ø.016”~.098” (0.4~2.5mm)
Max Feed Speed 394 ft/min (120m/min)
Spring Index 4
Feed Roller Pairs 2
Wire Feed Motor 2.7kw
Quill Motor 0.75kw
Slide Motor 1.2kw
Power 220v/ 3 phase
Dimension 43"x 55"x 75" (1100 x 140 x 1900mm)
Weight 2900 lbs. (1300 kgs)

Downloads

Delta DF-1025 Download

Videos

No product videos were found

The specifications are subject to change without notice.
